Mobile Pilot Reactors

High viscosity has never flowed so easily…

Designed to address issues such as easy cleaning of the reactor by moving the top dome or bottom vessel up and down according to the reaction to be performed, minimizing reactor damage in case of potential reaction errors, and emptying products with such high viscosity that they won’t flow through a valve, the Mobile Pilot Reactors have been introduced to you.

You can carry out all your particular high-viscosity reactions, such as adhesives, polyurethane-derived resins, pastes, and silicone derivatives. Loading, unloading, and cleaning are all possible.

Technical Specifications:

Reactor Capacity: 5-500 Liters

Operating Pressure: -0.7 ~ 10 bar (subject to change upon request)

Design Temperature: 220°C

Motor: Varies depending on the product

Blender Capacity: 10-750 Liters (optional)

Blender Pressure: 2 bar (subject to change upon request)

Blender Motor: Varies depending on the product

Cooling: External Chiller supply

Heating: Heat Transfer Oil

Surface: Mirror Polish

Material: 316 L-304-316 Ti-Hastelloy, Special Alloyed Stainless Steels

Sealing: Mechanical Seal (Magnetic Coupling can be applied depending on the process)

Lighting: LED System

Control Unit: PLC or Manual

Movement: Upper Dome or Vessel Up and Down







Technical specifications :

Reactor Capacity: 5-500 Lt
Operating Pressure: -0.7 ~ 10 bar (may vary depending on demand)
Design Temperature: 220 ºC
Engine: Change by Product
Blender Capacity: 10-750 Lt (optional)
Blender Pressure: 2 bar (may vary on request)
Blender Motor: Change by Product
Cooling: External Chiller Feed
Heating: Heat transfer oil
Surface: Mirror Polishing
Material: 316 L-304-316 Ti-Hastelloy, Special Alloy Stainless Steels
Sealing: Mechanical Seal (Magnetic Coupling applied according to process)
Lighting: Led System
Control Unit: PLC or Manual
Movement: Upper Group or Vessel Moving Up
